A
lot of homes we inspect in Florida have condensation on the HVAC duct vent
covers and moisture stains or mold on the ceiling around the vent. The cold air from the vent coming in contact
with warm air at the ceiling or uninsulated duct boots in the attic causes
condensation to form on the vent covers.
Frequently, this condensation causes moisture stains on the
ceiling. The moisture stains can be an
ongoing challenge if the cause of the condensation is not addressed.
The
water marks on the ceiling and the droplets of moisture on the vent cover are
likely caused by insufficient insulation on the ducts in the attic, inadequate
insulation or uninsulated vent boots, or leaking of hot / warm attic air around
the vent boots.
What
is a vent boot?
The vent boot is the box
in the attic that the air conditioning duct connects to on one side and the
vent cover on the ceiling is screwed into.
Newer boots are often constructed out of insulation board or duct
board. The older types of boots were
constructed out of metal.
The above picture shows an uninsulated vent
boot attached to the HVAC duct. The vent
cover connects to the vent boot on the inside of the ceiling. This boot has no insulation and the joints
are not sealed well. The sealant between
the boot and the ductwork is leaking and there is no sealant between the duct
and the ceiling. Moisture accumulating
on the vent boot drips down until it is absorbed by the drywall ceiling board
causing moisture stains around the vent cover.
People often mistake the dark stains that sometime
form around the vent for mold. The plausible
cause of the dark stains is the vent boot was not sealed to the ceiling board. The dust from the attic, then sticks to and stains
the moist drywall board around the vent cover.
When
you see the stains around your ceiling vent covers don’t ignore them. Water damage is costly to repair and moist
conditions may encourage mold growth.
Random Moisture
Stains on your Ceiling
If you have random stains on the ceiling; it may be the joints are not sufficiently
insulated or sealed. Moisture stains are
visible at the joints of the ductwork in the attic in the picture above. Condensation forms on the joint and may not
evaporate in the attic. If the
condensation continues to drip, it may saturate the insulation and cause
moisture stains on your ceiling.
Recommendation: We recommend sealing the joints to prevent
cooling loss in the attic and random stains on the ceiling. Sealing the joints will also improve the efficiency
of your HVAC system and help reduce your cooling costs.
Main Causes of Condensation at AC Vents
Not enough insulation on the ducts themselves
Cold air traveling
through your ductwork in a warm or hot attic forms condensation if the duct is
uninsulated or under insulated. The air ducts in the attic should be well
insulated. You should have your air
conditioning system and ducts inspected if it struggles to maintain a
comfortable inside temperature on hot days or you notice condensation on the
ceiling or vent cover.
The insulation on the
duct above was separated from the duct.
Condensation had formed in the duct vapor barrier and over time had stained
the middle of the ceiling.
Recommendation: Ducts in the attic should be
well insulated and in good repair.
Damaged or old under insulated ducts should be replaced. Consider replacing the ductwork in the attic
if it is 20yrs or older. It will be a
good investment that will be easily recouped and will save you money on your future
electric bills.
Uninsulated vent
‘boot’
The metal box in your
attic that attaches to the duct and the vent cover screws to is the boot. In an attic in Florida, the uninsulated boot
will generate large amounts of condensation due to the cold air in the boot and
the hot air in the attic.
Above is an uninsulated
galvanized duct boot. This boot was cold in the hot attic and caused water to
condense on it and drip onto the ceiling.
Recommendation:
We recommend having an HVAC contractor evaluate the condition of the
ductwork. Sealing the duct to vent boot joint and insulating old metal
ducts will help reduce condensation around the vents. Older
deteriorated ductwork should be replaced.
Dark Stains around your vent Cover
Dark stains around your vent covers may be mold, but more likely it is dust collecting on the damp
ceiling. If the boot is not properly
sealed to the ceiling, it will allow attic dust or dirt to seep out of the crack
between the ceiling and the vent cover. Also
you may discover a leak where the vent boot attaches to the duct. If not
properly sealed, the cold air leaks out, meets up with the warm attic air and
creates condensation.
Recommendation: Find and seal the leak. If the problem vent is
easy to access from your attic, you may be able to check for and fix the
problem yourself. We recommend consulting with a local HVAC contractor to
evaluate and repair the HVAC ducts.
Covering Stains around the Vent Cover
The dark or water stains
around your vent cover are difficult to cover.
When the repairs have been made, the ducts have been caulked and no more
condensation is present on the covers it will be time to cover the stains.
Normal ceiling paint will not cover up these stains. Moisture and dirt stains around the vent
cover are stubborn stains. Even with multiple coats of ceiling paint, the
stains continue to bleed through the ceiling paint.
Recommendation: We recommend you first cover the stains with
two coats of KILZ 2 Multi Surface Primer & Stainblocker then paint with
your choice of ceiling paint.
